Janam XG3-PNKANDNV01 Rugged Gun Mobile Computer (XG3, Android, 1D, Numeric)

XG3 | ERGONOMIC DESIGN IN A RUGGED MOBILE COMPUTER

The XG3 is Janam’s next-generation, gun-shaped, rugged mobile computer designed to excel in the most challenging environments. Eliminating the weight and bulk associated with competitive devices, Janam’s XG3 is the lightest industrial-grade mobile computer in its class at under 22 oz.

Built to withstand the rigors of all-day, every-day use in manufacturing facilities, distribution centers, plant floors, loading docks, ports and other demanding workspaces, the XG3 pairs breakthrough ergonomic design with the latest technological advancements, enabling mobile workers to increase productivity and improve operational efficiencies. With its pistol grip optimized for user comfort and a choice between Honeywell’s Adaptus® imaging technology and Zebra’s SE965 extended-range 1D laser scan engine, the XG3 is optimized for scan-intensive, extended shift use. Features include a brilliant 3.5-inch VGA TFT color display with hardened glass, ARM Cortex-A8 CPU @1GHz and choice of keypads to provide the performance, power efficiency and flexibility that enterprise and government customers require. The XG3 also delivers exceptional battery life with a standard 5200mAh hot-swappable Li-ion battery.

Janam’s XG3 rugged mobile computer is UL-certified for use in hazardous environments, sealed to IP65 standards and survives repeated 6' drops to concrete. A standard 2-year warranty provides customers with the level of service they require, at no additional cost. It’s technology at work.

Model

Model number: XG3
Model type: Rugged gun-grip mobile computer
Manufacturer: Janam Technologies LLC

Physical Characteristics

Dimensions: 7.4" (188 mm) L x 3.1" (79 mm) W x 8.3" (211 mm) D
Weight: 21.7 oz. (643.5 g) with standard battery
Display: 3.5" Color TFT VGA; 600 NITS
Touch panel: Resistive touchscreen
Keypad: 34-key numeric (alpha shifted)
Indicators: Tri-color LEDs, at top, rear and bottom; vibration; audio beep
Scan triggers: Pistol-grip trigger (located on handle, side and top)
Motion sensor: Accelerometer

System

Processor: ARM Cortex-A8 CPU @1GHz
Operating system: Android™ Jelly Bean 4.2
Memory: 512MB RAM, 1GB ROM

Power

Main battery: 5200mAh rechargeable and hot-swappable Li-ion battery

Data Collection

Zebra SE965; CDRH Class II/EC Class 2; 104 (+/- 12) scan/sec (bidirectional)

Environment

Electrostatic discharge (ESD): ± 15 kV air discharge, ± 8 kV contact discharge
Sealing: Rated IP65
Drop specification: Multiple 6-foot (1.8m) drops to concrete on all sides across a wide temperature range
Operating temp: -4°F to 140°F/-20°C to 60°C
Storage temp: -40°F to 158°F/-40°C to 70°C
Humidity: 95% RH non-condensing

Communication

WLAN: 802.11a/b/g/n
WLAN authentication: EAP (TLS, PEAP-MSCHAPv2, PEAP-GTC, PEAP-TLS, TTLS, EAP-FAST, LEAP) Encryption: WPA2 (AES-CCMP), WPA (TKIP), WEP
WPAN: Bluetooth v2.1 with EDR
USB 2.0
User-accessible microSD card slot
Audio: Speaker, microphone, 3.5mm headset jack, VoIP support

Warranty/Certifications

Warranty: 2 years
Safety: CSA C22.2 No.60950-1-03; UL60950; EN60950-1; EN60825
EMI: FCC Part 15B
RF: FCC Part 15B and 15C, RSS-210, ICES-003
Hazardous locations: UL Listing (US and Canada) Class I Div 2, Groups A, B, C, D
