Janam XT1-1TEARJCW00 Rugged Mini Tablet (XT1, Android, 2D, 3G EU, WiFi, BT, GPS, NFC, RFID)

XT1 | THE INDUSTRY’S LIGHTEST AND MOST POWERFUL RUGGED MINI-TABLET

In addition to Android™ operating system and a brilliant 5.9” WVGA display, the XT1 rugged mini-tablet comes equipped with 802.11a/b/g/n WLAN radio with enterprise-grade security and advanced 3G WWAN cellular technology, ensuring reliable data communication both inside and outside the four walls.

Integrated 2D scanning technology and a 5.0 megapixel camera allow mobile workers to accurately capture data, while lightning fast processing, motion-sensing accelerometer, high-sensitivity GPS and advanced power management provide on-the-go productivity.

The XT1 is certified for use in hazardous environments, is sealed to IP54 standards and can withstand multiple 3’/1m drops to concrete. Designed to excel in the most rigorous work settings, the XT1 supports demanding enterprise applications in field sales, field service, healthcare, hospitality and retail environments. A standard 2-year warranty provides customers with the level of service they require, at no additional cost. It’s technology at work.

Model

Model number: XT1
Model type: Rugged mini-tablet mobile computer
Manufacturer: Janam Technologies LLC

Physical Characteristics

Dimensions: 7.8" (200.5 mm) L x 3.9" (99.3 mm) W x 0.5" (14.7 mm) D
Weight: 13 oz. (370 g) with standard battery
Display: 5.9" TFT WVGA (800 x 480)
Touch panel: Capacitive touchscreen
External buttons: Power button, volume/programmable buttons
Indicators: Tri-color LEDs, vibration, audio beep
Motion sensors: G-Sensor Accelerometer

System

Processor: Dual-core ARM Cortex-A9 CPU @1.5GHz
Operating system: Android 4.2.2
Memory: 1GB RAM / 16GB ROM

Power

Main battery: 3000mAh rechargeable Li-ion battery

Data Collection

Imager: Honeywell N5600 with 2D Adaptus® Imaging Technology; 844 x 640 pixel CMOS area imager
Camera: 5.0 megapixel CMOS color rear-facing autofocus camera with user-controllable LED flash and 1.2 megapixel front-facing camera
RFID/NFC: Reads FeliCa, ISO14443 Type A, ISO14443 Type B, ISO15693 RFID tags in the 13.56 MHz range and all NFC card types

Environment

Electrostatic discharge (ESD): ± 8 kV air discharge, ± 4 kV contact discharge
Sealing: Rated IP54
Drop specification: Multiple 3-foot (1m) drops to concrete on all sides across a wide temperature range
Operating temp: 14°F to 122°F/-10°C to 50°C
Storage temp: -4°F to 140°F/-20°C to 60°C
Humidity: 0% to 90% RH non-condensing
Sterilization: 75% concentration alcohol rub

Communication

GPS: U-Blox GPS and Assisted GPS
WWAN: 3G (EU)
WLAN: 802.11a/b/g/n PICS Compliant
WLAN security: IEEE 802.1x; WEP; WPA/WPA2 (TKIP); WPA2 (PSK, AES); EAP-TTLS; EAP-TLS; PEAPv0-MSCHAPv2; LEAP
WPAN: Bluetooth v4.0 (BLE)
Mini USB
User-accessible microSD card slot with SD and SDHC support
Audio: 3.5mm headset jack, mono speaker, mono microphone, micro HD output (out)

Warranty/Certifications

Warranty: 2 years
Safety: IEC60950-1/A1:2009
EMI: FCC Part 15B; EN5502; EN55024; EN61000-3-2; EN61000-3-3
RF: FCC Part 15B and 15C; EN301 489-1; EN301 489-3; EN 301 489-7; EN301 489-17; EN 301 489-24; EN300 328; EN301 893; EN300 440; EN301 908-1; EN301 908-2; EN301 511; EN302 291-1; EN302 291-2; EN50566; EN62209-2; EN62479; EN50332
Hazardous locations: UL Listing (US and Canada) Class I Div 2, Groups A, B, C, D
