Unitech HT682-9460UARG Rugged Handheld Mobile Computer HT682 (Windows), 1D Laser
HT682 mobile computer, 1D laser, WiFi, Bluetooth, Windows CE 6.0 Pro. Includes USB cradle, battery, and power adapter. Purchase charging cradle and additional cables separately.
HT682 | Rugged Handheld Computer (Windows)
The Unitech HT682 is a rugged handheld computer ideally suited for the toughest environments and most challenging projects. The HT630's area imager provides high-volume scanning in logistics, manufacturing, and transportation applications. Fast, rugged, and compact – the HT682 handheld computer offers incredible value.
- Expanded memory capacity and lightning-fast processor
- Ergonomically designed, lightweight, fast and powerful
- Withstands 6-foot drops to concrete
- IP65 environmentally sealed against water and dust
- Includes USB cradle, battery and power adapter
- Warranty: 1 year
Physical Characteristics
Dimensions: 6.7" (170 mm) L x 2.2" (55 mm) W x 1.2" (30 mm) D
Weight: 11 oz. (310 g) with standard battery pack
Display: 2.8" QVGA, color transflective TFT, with touchscreen and backlight
Keypad: 22 keys, including 4-direction, function, and numeric keys
Indicator: LEDs, vibration
System
CPU: 800MHz TI OMAP AM3703
Operating system: Microsoft Windows CE 6.0 Pro
Memory: 512 MB SDRAM / 512 MB Flash ROM
Power
Main battery: 8.14 Watt-Hour 3.7V @ 2200 mAh; 14.8 Watt- Hour 3.7V @ 4000mAH
Operating time: Over 12 hours
Backup capability: Over 72 hours
Data Capture
Scanning: 1D Laser
Symbologies: UPC-A/E, EAN-8/13,Codaba, Code 39, Code 39 full ASCI, Code 93,Code32, Interleaved & Std. 2 of 5, EAN 128, Code 11, Delta, MSI/Plessey, Code 128, Toshiba
Environment
Sealing: Rated IP65
Drop Specification: Multiple 6' (1.8m) drops to concrete
Operating temp: 14°F to 122°F/-10°C to 50°C
Storage temp: -4°F to 140°F/-20°C to 60°C
Humidity: 5% to 95% RH non-condensing
Communication
USB 2.0
USB Host
802.11 a/b/g/n WiFi
Bluetooth 2.1 + EDR
Micro SD expansion slot up to 32 GB
Software
MS: Microsoft Visual Studio 2005 / 2008
SDK: Unitech Handheld terminal SDK
Warranty/Certifications
Warranty: 1 Year
Certifications: CE, FCC, BSMI, VCCI, CCC, SRRC, RoHS compliance
| Manufacturer Part No. | HT682-9460UARG |
|---|---|
| Model | HT682 |
| Manufacturer Product Link | http://us.ute.com/products_info.php?pc1=48&pc2=453&rbu=5&pid=1281 |
| User Interface | 22-Key, Function Buttons, Numeric Keypad |
| Operating System | Windows CE 6.0 Pro |
| Battery | Lithium-Ion Battery |
| IP Rating | IP65 |
| Scanner Features | Vibration Feedback |
| Durability | Rugged |
| Barcode Type | 1D |
| Connectivity | 802.11a/b/g/n, Bluetooth, Micro SD Slot, USB 2.0, USB Host, WiFi |
| Screen Size (Inches) | 2.8 |
| Processor | 800 MHz |
| RAM | 512 MB |
| Storage Memory | 512 MB |
| MIMO Configuration | N/A |
| Scan Type | Laser |
| Scanning Range | Standard |
