Unitech PA692-9261UMDG Rugged Handheld Computer PA692 (Windows), 1D, Numeric
In Stock: Usually ships within 1-3 days
PA692 mobile computer, 1D laser, 26-key numeric keypad, camera, WiFi, Bluetooth, WEH 6.5. Includes battery, USB cable, and power adapter. Purchase charging cradle and additional cables separately.
PA692 | Rugged Handheld Computer (Windows)
The PA692 is a rugged handheld computer designed to yield impressive results in various work environments, facilitating all types of data collection operations, particularly those for field service, transportation, public safety, and DSD.
The Unitech PA692 rugged handheld computer offers different data collection, keypad, and operating system options to ensure this device meets your specific needs and excels in your workspace.
Physical Characteristics
Dimensions: 7" (177 mm) L x 2.9" (74 mm) W x 1.6" (40 mm) D
Weight: 13.76 oz. (390 g) with standard battery pack
Display: Transflective color 3.8" full WVGA with backlight 800 x 480 sunlight readable LCD
Keypad: Integrated 26-key numeric keypad
Camera: 5.0 megapixel autofocus camera with flash
Unitech MPEG-4 video codec (VGA resolution)
Indicator: LEDs, vibration
System
CPU: 1GHz TI AM3715
Operating system: Windows Embedded Handheld 6.5 Professional
Memory: 512 MB Mobile DDR, 512 MB NAND Flash
Power
Main battery: 8.14 Watt-Hour 3.7V @2200 mAh, 14.8 Watt- Hour 3.7V @4000 mAh
Backup battery: NiMH battery supports 2 hours backup
Data Capture
1D laser scanner: UPC-A/E, EAN-8/13, Codabar, Code 39, Code 39 full ASCI, Code 93,Code 32, Interleaved & Std. 2 of 5, EAN 128, Code 11, Delta, MSI/Plessey, Code 128, Toshiba
Environment
Sealing: Rated IP65
Drop Specification: 3-foot drop test to concrete
Operating temp: 32°F to 122°F/0°C to 50°C
Storage temp: -4°F to 140°F/-20°C to 60°C
Humidity: 5% to 95% non-condensing
Communication
USB 1.1 Host & Client
802.11 a/b/g WiFi
Bluetooth 2.1 + EDR
Micro SD expansion slot up to 32 GB
Software
Microsoft Visual Studio 2005/2008
Mobile SIP(VoIP)
Auto Installer
Warranty/Certifications
Warranty: 1 Year
Certifications: CE, FCC, BSMI, VCCI, CCC, RoHS compliance
| Manufacturer Part No. | PA692-9261UMDG |
|---|---|
| Model | PA692 |
| Manufacturer Product Link | http://us.ute.com/products_info.php?pc1=48&pc2=453&rbu=5&pid=1283 |
| User Interface | Numeric Keypad, Touchscreen |
| Operating System | Windows Embedded Handheld 6.5 |
| Battery | Lithium-Ion Battery |
| IP Rating | IP65 |
| Scanner Features | Camera, RFID Enabled, Vibration Feedback |
| Durability | Rugged |
| Barcode Type | 1D |
| Connectivity | 802.11a/b/g, Bluetooth, Micro SD Slot, USB, USB Host, WiFi |
| Screen Resolution | 800 x 480 |
| Screen Size (Inches) | 3.8 |
| Processor | 1 GHz |
| RAM | 512 MB |
| Storage Memory | 512 MB |
| MIMO Configuration | N/A |
| Scan Type | Laser |
| Scanning Range | Standard |
