Unitech PA700-NAV2SG2 Rugged Handheld Computer PA700V (Android), 2D Imager, 4G LTE Verizon

PA700 | Rugged Handheld Computer (Android)

Unitech PA700 brings a new level of compact size, functionality and durable construction to an enterprise digital assistant. Not only delivering a slim device with stylish look, but also equipped with industrial-grade functions to meet the needs in mobile workforce. PA700 is an ideal portable tool to streamline work process in retail and field service.

Running on Android 4.3 Jelly Bean operation system, PA700 provides superior fast and smooth operation as well as combining 1D barcode scanning, UHF/HF RFID and 5.0MP auto focus camera in one handheld device, delivering maximum efficiency to users.

Physical Characteristics

Dimensions: 6.3" (160 mm) L x 3.1" (78.7 mm) W x 0.7" (18 mm) D (without engine)
Weight: 10 oz. (283.5 g) with battery
Display: Gorilla Glass II with 5-point capacitive touch panel 4.7" color transmissive TFT 720 x 1280 high-resolution LCD
Keypad: 4 function keys, 2 scan keys, volume keys, power keys
Camera: 5 Megapixel CMOS sensor camera with auto focus, LED flash light
Indicator: LED (charge/message), vibration
Supported languages: English, Simp. Chinese, Traditional Chinese, Japanese, Spanish, German, French

System

CPU: 1.5Ghz TI OMAP 4470 Dual Core Processor
Operating system: Android 4.3 Jelly Bean
Memory: 1 GB Mobile DDR, 8 GB eMMC Flash

Power

Main battery: 11.91Wh 3.7V @ 3220mAh Li-Polymer battery pack
Backup battery: 1 hour

Data Collection

Near Field Communication: HF/NFC, Frequency 13.56MHz, Support ISO15693, ISO14443A, ISO14443B
2D area imager: PDF417, Micro PDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX)

Environment

Sealing: Rated IP65
Drop Specification: Multiple 4-foot drop test
Operating temp: 14°F to 122°F/-10°C to 50°C
Storage temp: -4°F to 140°F/-20°C to 60°C
Humidity: 5% to 95% non-condensing

Communication

USB 2.0 OTG
802.11 b/g/n WiFi
Bluetooth 4.0
Micro SD expansion slot up to 32 GB
GPS
WWAN: UMTS / HSPA+, 3GPP Release 6 / 7 Dual Band UMTS/HSPA+ (850, 1900 MHz), Dual Band GSM (850/1900 MHz)

Software

Android 4.1.1 API Level 16

Warranty/Certifications

Warranty: 1 Year
Certifications: CE, NCC, FCC, BSMI, VCCI, CCC, RoHS compliance
